Sugden Audio -
The "Mighty" MPA-4 Mono Block Amplifiers.
MPA-4
Sugden Audio ...Rescuing Music From Technology.
Personal Note:
Everytime I demo or install a pair of these I'm impressed all-over again at how good they are.
The last pair went with a pair of Dyn-Audio Contour 3.3's and without exageration, they just sounded like magic.
If you're looking for Amplification in this league, you owe it to yourself to audition these Mono-blocks.
The stereo power amplifier SPA-4 and its big brother, mono power amplifier MPA-4, have been developed to present a holographic three dimensional soundstage where the listener can almost walk in and touch the musicians.
Tremendous headroom is available in which to develop a wonderfully dynamic portrayal of music in all of its moods - ‘simply more music’.
The stereo power amp has facilities for asymmetric (phono/RCA) or balanced inputs, the latter utilising a virtual transformer (discreet) balanced input circuit.
The power amplifiers are symmetrical, current feedback, dc-coupled, gain stages with servo controlled dc off-set and multi emitter output devices.
In the balanced mono amps the two power output stages of the stereo power amp are connected in balanced mode giving a mono amplifier.
The mono amplifiers give single channel power twice that of the stereo amps.
Among some of the gains of the balanced configuration is a much lower noise floor, even greater dynamics and a rock solid musical sound stage.
Personal Note:
Everytime I demo or install a pair of these I'm impressed all-over again at how good they are.
The last pair went with a pair of Dyn-Audio Contour 3.3's and without exageration, they just sounded like magic.
If you're looking for Amplification in this league, you owe it to yourself to audition these Mono-blocks.
The stereo power amplifier SPA-4 and its big brother, mono power amplifier MPA-4, have been developed to present a holographic three dimensional soundstage where the listener can almost walk in and touch the musicians.
Tremendous headroom is available in which to develop a wonderfully dynamic portrayal of music in all of its moods - ‘simply more music’.
The stereo power amp has facilities for asymmetric (phono/RCA) or balanced inputs, the latter utilising a virtual transformer (discreet) balanced input circuit.
The power amplifiers are symmetrical, current feedback, dc-coupled, gain stages with servo controlled dc off-set and multi emitter output devices.
In the balanced mono amps the two power output stages of the stereo power amp are connected in balanced mode giving a mono amplifier.
The mono amplifiers give single channel power twice that of the stereo amps.
Among some of the gains of the balanced configuration is a much lower noise floor, even greater dynamics and a rock solid musical sound stage.
[Read More]
> Send to a Friend
> Contact us about this product
> Purchase this product
Our Price
$19,999
Facilities.
Inputs: Mono balanced
Outputs: Single pair multi-way locking binding posts
Specifications.
Input Sensitivity: 1Volt for full output
Power output: 165 Watts into 8 Ohms both channels working
Frequency response: +/-0dB 15Hz-30kHz
Bandwidth: -3dB points 2Hz-200kHz
Signal to noise: >85dB
Gross weight: (Packed) 25kgs x 2
Dimensions: 250 x 430 x 360mm (hwd)
Inputs: Mono balanced
Outputs: Single pair multi-way locking binding posts
Specifications.
Input Sensitivity: 1Volt for full output
Power output: 165 Watts into 8 Ohms both channels working
Frequency response: +/-0dB 15Hz-30kHz
Bandwidth: -3dB points 2Hz-200kHz
Signal to noise: >85dB
Gross weight: (Packed) 25kgs x 2
Dimensions: 250 x 430 x 360mm (hwd)
