Dali: Award Winning Speakers -
Designed to Move Lots of Air with Power and Precision.
E-9F

The launch of the DALI SUB E-9 F marks a new stage of what is possible at this level of subwoofers! The SUB E-9 features a 9” woofer, capable of moving lots of air with power and precision. The cone is made from pure aluminium for maximum stiffness and a becoming exterior.



PRODUCT DETAILS

The launch of the DALI SUB E-9 F marks a new stage of what is possible at this level of subwoofers!

The SUB E-9 features a 9” woofer, capable of moving lots of air with power and precision. The cone is made from pure aluminium for maximum stiffness and a becoming exterior. Furthermore, the heavy magnet system wields a massive 4-layer, long-stroke voice coil.

All in all, the heavy-duty abilities of this “motor system” ensure that the woofer always follows the signal from the amplifier!

The heart of this subwoofer is the 170W RMS Class D amplifier with a highly linear response. Embracing a classic DALI trademark, it simply acts as a total low frequency extension of your AV system. The result is a powerful, wellbalanced bass reproduction and flawless integration with your speakers. In addition, the integrated limiter helps protecting your subwoofer against overloading.

The back plate of SUB E-9 F features controls for volume adjustment, phase, and upper cut-off frequency, while the power on/off function works automatically via signal detection. And with the options for LFE or LINE inputs, this subwoofer easily accompanies any AV set up.

SUB E-9 F is elevated from the floor by cone shaped rubber feet, while a down-firing bass port allows positioning directly against the wall.

The DALI SUB E-9 F is recommended as compliment to the compact models of the OBERONSPEKTORZENSOR and FAZON series. On top of this it is compatible with all DALI loudspeakers as the perfect completion of a DALI stereo or surround set up.

[Read More]
Our Price $1,199

FINISHES

Product series SUBWOOFERS
Frequency Range (+/-3 dB) [Hz] 37 - 200
Maximum SPL [dB] 111
Crossover Frequency [Hz] 40 - 120
Low frequency driver, Quantity 1 x 9" long stroke
Low frequency driver, Diaphragm type Aluminium
Enclosure type Bass Reflex
Bass Reflex Tuning Frequency [Hz] 39.0
Max. Amplifier Power Output [RMS watt] 220
Continous IEC Power Output [RMS watt] 170
Input Impedance [ohms] 25k
Connection Input Mono (LFE)
RCA
Stereo (low-pass filtered)
Magnetic Shielding No
Recommended Placement Floor
Recommended Distance From Wall [cm] 10 - 30
Functions Crossover Frequency
Phase Switch
Standby (Auto Power) On/Off Switch
Volume (Gain)
Max. Power Consumption [W] 250
Dimensions With Base (HxWxD) [mm] 307 x 288 x 311
Accessories Included Manual
Weight [kg]

11.0
